    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    Ask Lasest Price
    Brand Name : Crowns
    Certification : ISO 9001; CE
    Price : $110-$1050/set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000SETS/PER YEAR
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    Introduction
    The housing usually is made of stainless steel. The filter uses cartridge as the filter medium. The cartridge can be: Melt blow cartridge/string wound cartridge/PP folded cartridge/nylon membrane cartridge/PES cartridge/PTFE cartridge. A different filtering element is selected according to different filtered material and the designed technology to reach the quality requirements. The filter precision range :0.1-60um; the model includes 10 inches, 20inches, 30inches and 40 inches; connection ports:plug port and flat port.
    Working principle
    The liquid will be fed into the filter from the inlet, then go through the cartridge from external side to inner side, then discharge from outlet. While the filtering, impurities will be trapped by the cartridge, so that realize filtering effect.

    Models Commonly Used For Your Choice
    Model
    Flow in theory(T/H)
    The housing diameter(mm)
    Height (mm)
    Inlet/Outlet (DN)
    YWLX10-1
    0.1-0.3
    102
    500
    25-32
    YWLX20-1
    0.3-0.5
    102
    750
    25-32
    YWLX30-1
    1.2
    102
    1000
    25-32
    YWLX40-1
    1.5
    102
    1250
    25-32
    YWLX10-3
    1.2
    160
    650
    25-40
    YWLX20-3
    1.5
    160
    900
    25-40
    YWLX30-3
    3.6
    160
    1150
    25-40
    YWLX40-3
    4.5
    160
    1400
    25-40
    YWLX20-5
    2.5
    200
    900
    25-50
    YWLX30-5
    6
    200
    1150
    25-50
    YWLX40-5
    7.5
    200
    1400
    25-50
    YWLX20-7
    3.5
    230
    900
    25-50
    YWLX30-7
    8.4
    230
    1150
    25-50
    YWLX40-7
    10.5
    230
    1400
    25-50
    YWLX20-9
    4.5
    300
    900
    25-50
    YWLX30-9
    10.8
    300
    1150
    25-50
    YWLX40-9
    13.5
    300
    1400
    25-50
    We Also Can Custom For You As Your Demands!

    Advantages of Large flow cartridge filter housing:

    ◆ High capacity, small size
    ◆ Easy to replace the filter cartridge, labor saving
    ◆ After cleaning the filter cartridge can be used repeatedly to save cost
    ◆ Filter precision reached 0.2-500 μm
    ◆ Lower leakage risk ensures high quality
    ◆ High working pressure, low pressure loss, low operation cost and energy saving
    ◆ various installation model for choice.
    Application of large flow folding filter element:
    Desalination,Food and beverage,Power plant water treatment,microelectronics,Steel plant water treatment,Petrochemicals
    Large flow folding filter element use:
    1. RO pre-filtration, seawater desalination desalination
    2. Condensed water filtration
    3. Filtration of drinking water and edible oil
    4. Filtration of oilfield reinjection water
    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    304/316L Stainless Steel Single Multi Cartridge Filter Housing For Wine Oil Water Treatment Industrial Water Filter

    FAQ

    Q1 : Where is your factory located?
    A1 : Qingdao crowns machinery co.,ltd is located at Huangdao district ,Qingdao city, China

    Q2 : Are you an integrated supplier for industrial filter machine ?
    A2 : Yes, we can provide the complete solution line to customer according to customer’s requirement.

    Q3 : How about the quality control in your factory?
    A3 : Qingdao crowns has the SOP (Standard Operation Procedure) and all the production step must follow

    up this SOP. Every machine needs at least automatic running over 72 hours and must be inspected carefully

    before shipment.

    Q4 : Will you offer the pre-sales service?
    A4 : Yes, we have an experienced pre-sales team to support customers not only including machine, technology

    also water electrical,machine layout in factory, etc.

    Q5 : What about the after-service? Will you send your engineer to my country to help commission and install the

    machine?
    A5 : Surely, we have many experience technical engineers for oversea service, they would help you install machine

    and support training to workers also.

    Q6 : What is the delivery time of the machine?
    A6 : Actually, the delivery time of the machines is depended on the machine options. Normally, the delivery

    time of standard machine could be within 10-30 days

    Q7 : What is the warranty of the machine ?
    A7 : The whole machine’s warranty period is 12 months and key parts will be depended.


    Q8 : Do you provide any spare parts with machine?
    A8 : Yes, CROWNS will provide one set standard spare parts to customer according to different machines
