    Customized brush scraper type industrial automatic self cleaning filter industrial water filters

    Screen Filter Automatic Self Clean Back-flushing Backwash Filter 25-5000 um 8000 m3h

    Product overview


    Factory sale customized brush scraper type industrial automatic self cleaning filter auto clean self-cleaning water filter price

    The inside structure of the automatic self-cleaning brush filter is made up of the stainless steel strainer and stainless steel wire brush and transmission part. The washing and the drainage are automatically finished by the drive motor and electrical valve. The operation way is automatic running (manual running is also Ok), It is with the double function of the pressure difference and regularly automatic drainage. The automation part takes use of the most advanced and reliable PLC in the world.


    When the water flow gets through the filter, the impurity in the water is held by the strainer With the increase of the impurity accumulated on the surface of the strainer, the pressure difference reaches 0.04Mpa. The switch of the pressure difference will give out a signal while the PLC sends an instruction to start the drive motor and open the drainage valve; the impurity accumulated on the strainer will be brushed off with the rotating brush and discharged from the drainage exit. The whole process of brushing and draining require no personal operation and without machine halt. At the same time, the equipment is with the function of regular washing and draining and manual washing and draining to make sure that the water output is safe and reliable in any case.

    Product name
    Automatic self cleaning filter
    Material
    SUS304, SUS316, SUS316L
    Type
    JYSCF-50
    Inlet/Outlet Size
    DN50
    Filter Type
    Wedge Wire Screen Filter
    Filtration precision
    25-500 Micron or as request
    Height(H/mm)
    1130
    Filter House Diameter(mm)
    219
    Power Motor(KW)
    0.55
    Working Pressure(Bar)
    <10

    Product Specifications




    Q1 : Where is your factory located?
    A1 : Qingdao crowns machinery co.,ltd is located at Huangdao district ,Qingdao city, China

    Q2 : Are you an integrated supplier for
    industrial filter machine ?
    A2 : Yes, we can provide the complete solution line to customer according to customer’s requirement.

    Q3 : How about the quality control in your factory?
    A3 : Qingdao crowns has the SOP (Standard Operation Procedure) and all the production step must follow

    up this SOP. Every machine needs at least automatic running over 72 hours and must be inspected carefully

    before shipment.

    Q4 : Will you offer the pre-sales service?
    A4 : Yes, we have an experienced pre-sales team to support customers not only including machine, technology

    also water electrical,machine layout in factory, etc.

    Q5 : What about the after-service? Will you send your engineer to my country to help commission and install the

    machine?
    A5 : Surely, we have many experience technical engineers for oversea service, they would help you install machine

    and support training to workers also.

    Q6 : What is the delivery time of the machine?
    A6 : Actually, the delivery time of the machines is depended on the machine options. Normally, the delivery

    time of standard machine could be within 10-30 days

    Q7 : What is the warranty of the machine ?
    A7 : The whole machine’s warranty period is 12 months and key parts will be depended.

    Q8 : Do you provide any spare parts with machine?
    A8 : Yes, CROWNS will provide one set standard spare parts to customer according to different machines
